Keep Oil Out of your Ford F150/Raptor Air Intake System!
It's no secret that the Ford 3.5L Ecoboost® turbo motors suffer from oil control problems causing the oil to blow through and coat the intake manifold and gunking up the throttle body and intake valves, lowering the effective octane, and generally degrading engine performance. The higher your boost levels and milage the more apparent these problems become.
The solution to this problem has finally arrived. The BMS dual oil catch cans. V2 now with OEM quick connect PCV fittings and premade hoses for a quick install/removal. While there are other catch cans on the market they all fall short in various areas. Some utilize hoses that are too small and runs that are too long to allow proper PCV ventilation causing internal motor/ring sealing issues. Some have insufficient, cheap, or even no internal baffle system while others have internal baffles systems that are too restrictive. Some even bypass the PCV system all together venting crankcase gas and odor to the atmosphere.
To solve these problems BMS designed our dual oil catch can kit for 3.5L EcoBoost powered F-150 trucks from the ground up. The cans and internals features 100% CNC machining with zero welding for a precision fit and long life. The cans themselves are guaranteed for the life of the vehicle and contain a triple baffle. The hoses exceed the OEM PCV piping in diameter and that flow rate is maintained throughout the entire oil catch can ensuring no excessive crankcase pressure buildup and have OEM quick connect fittings for quick install/removal. The BMS OCC retains the factory fully closed loop PCV operation preventing any PCV vapor from leaking to atmosphere. The mounting locations are selected to minimize the line length, make checking and emptying the cans easy, and look good at the same time.
Simply unscrew the base of the can or use the drain plug to safely dispose of captured oil with the rest of your used motor oil during oil changes.
Features & Benefits
• Improves intake airflow
• Helps protect long term engine health
• Triple-baffle air/oil separation
• Free-flow, low restriction design
• Maintains factory closed-loop PCV operation
• OEM-style quick connect PCV fittings
• Large, unrestricted inlet and outlet ports
• High-flow design helps reduce crankcase pressure
• CNC-machined billet aluminum construction
• Black anodized finish
• Firewall-mounted for a clean engine bay look
• Easy empty service every 3 to 6 months
• 1/8-inch NPT drain plug included
• Made in the USA
• Lifetime warranty
Vehicle Fitment
Ford F-150
- 2015+ Ford F-150 3.5L V6 EcoBoost
- 2015+ Ford F-150 2.7L V6 EcoBoost
Ford F-150 Raptor
- 2017-2020 Gen 2 F-150 Raptor 3.5L V6 EcoBoost
- 2021+ Gen 3 F-150 Raptor 3.5L V6 EcoBoost
Catch can dimensions and specs
Can dimensions with lid: 4.4" (111mm) Tall
Can diameter: 2.5" (63.7mm)
Lid length: Back to nozzle end: 4" (101mm)
Nozzle outer diameter: .75" (19.2mm)
Nozzle inner diameter: 0.669" (17mm)
What's Included in the full kit. (Both cans)
(2) Burger Motorsports Triple Baffle Billet Oil Catch Cans
(2) Left and Right Billet Brackets, (2) lock nuts (8) hex screws
(1) 90º female quick connect OEM fitting with 17.5" hose
(1) 90º female quick connect OEM fitting with 19.5" hose
(1) Straight female quick connect OEM fitting with 19" hose
(1) 45º female quick connect OEM fitting with 17" hose
Now with OEM quick connect PCV fittings and premade hoses for a quick install/removal.
